Product Details
Place of Origin: GUANGDONG
Brand Name: OLAX
Certification: ce.ROHS
Model Number: MF980L
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiated price
Packaging Details: Product size: 13.5*11.5*2.2cm Packing size: 37*30*28cm Weight:0.15kg Packing weight: 96KG/CTN Carton: 60pcs/CTN
Delivery Time: 28-35 workdays
Payment Terms: T/T
Supply Ability: 10000pcs/month
Product Name: |
4G LTE Mifis Wireless Router |
Warranty: |
12 Months |
Battery: |
2100mah Lithium Battery (removable) |
Wireless: |
DL 150Mbps/UpLoad 50Mbps |
User: |
10 Wifi Users |
Color: |
White With Screen |
SIM Slot: |
One |
WPS: |
SUPPORT |
Product Name: |
4G LTE Mifis Wireless Router |
Warranty: |
12 Months |
Battery: |
2100mah Lithium Battery (removable) |
Wireless: |
DL 150Mbps/UpLoad 50Mbps |
User: |
10 Wifi Users |
Color: |
White With Screen |
SIM Slot: |
One |
WPS: |
SUPPORT |
4G Mobile Wifi Modem Mifis Router for Asian countries Traveller OLAX MF980L
Product Description
Before order , please check the frequency of your operator whether it can work in our router, the checking link as below:
https://www.frequencycheck.com/
How to search: Click on the link and enter the name of the country to check
MF980L frequency band as follow:
4G/FDD:B1/B3/B5/B8/
4GTDD:B38/B39/B40/B41
3G WCDMA:B1/B8(2100/900MHZ)
Features
Lasting Power Supply : 10 hours Enduring time based on high quality 2100mAh battery
High performance chip: wifi chip can provide up to 10 users at the same time, easy to enjoy wireless life
Application Scenarios:Home, store, enterprise, also can be applied in some mobile scenarios, such as bus, RV, bus, self-driving, temporary outdoor activities, etc.
4.The 4G network can be used not only through the computer to use the 4G network speed, but also through cell phones, pads and other mobile terminals, which can be convenient for people to work, study, live and play
5.Memory card: up to 32GB memory card support
How to use :
Put in the SIM Card to surf the internet easily
Easy and fast charging using USB interface
MF980L package Contents:
1*device 1* 2100mah Battery
1*USB cable 1* User manual
OLAX MF980L Wireless Router
| Model Number | MF980L | Remarks |
| The processor | Cat4 ZX297520V3 | |
| spectrum | FDD LTE: B1/B2/B3/B4/B5/B7/B8/B20/B28/B12/B13/B17/B66 | |
| TDD LTE: B38/B39/B40/B41 | ||
| TD-SCDMA: B34/B39 | ||
| WCDMA: B1/B5/B8 | ||
| Peak rate | LTE download:100.8Mbps, upload:51.0Mbps (Category 4) | |
| TD-SCDMA download:4.2Mbps, upload: 2.2Mbps | ||
| WCDMA download:42Mbps, upload: 5.76Mbps | ||
| The keys | The power button | |
| The WPS switch button | ||
| Restore the factory button (pinhole) | ||
| TF card | Upward compatible to 32 gb | |
| WIFI | Support 802.11 b/g/n | |
| The battery | 2100 mah lithium battery | |
| interface | MicroUSB interface | |
| Standard USIM interface | ||
| MicroSD interface | ||
| The adapter | The input voltage:100V~240V,50Hz~60Hz | |
| The output voltage:5V DC±10% | ||
| The output current:1A | ||
| Charging interface | Micro 5pin | |
| Working temperature | -10°C to 60°C | |
| Working humidity | 5% - 65% | |
| Storage temperature | -30°C to 80°C | |
| Store humidity | 5% to 95% | |
| Software information | ||
| The operating system | Win7, Windows XP, Vista, Mac OS | |
| language | Chinese/English | Support multiple languages |
| Shared) | Up to 10 users | |
| Set up the) | support | |
| SMS | Support mobile and Unicom conventional card receiving and sending, telecommunication cards do not support | |
| The phone book | support | The phone book/APN/ WIFI /Device /Routing/Firewall Settings |
| size | 59x98x15.5 mm | 98mmX58.5mmX15mm(For reference only) |
| The weight of the | 86.04g | |
| The standby time | Can reach more than 50 hours | Ultimately decided by the battery |
| Work hours | Can reach more than 7 hours | Ultimately decided by the battery |
